Internal Parts

GEAR, LINK WORM - RU6-0795-000CN

Link worm gear

GEAR, 18T/29T - RU6-0775-000CN

18/29-tooth gear - For simplex models only

GEAR, 74T - RU6-0773-000CN

74-tooth gear - For the duplex models only

GEAR, 25T - RU6-0772-000CN

25-tooth gear - For the duplex models only

GEAR, 25T - RU6-0771-000CN

25-tooth gear - For the duplex models only

SCREW, STEPPED - RU5-9056-000CN

Stepped screw

SHAFT, RIGHT DOOR LINK - RU5-4979-000CN

Right door link lock

SPRING, TENSION - RU5-2632-000CN

Tension spring - Provides tension for lever arm that couples the drive gear to the toner cartridge

SPRING, TENSION - RU5-2563-000CN

Tension spring - Provides tension to the dust cover to retract back to its home position

GEAR 133T - RU5-0546-020CN

133-tooth gear - Big gear that is located on the gear plateThis part replaces the following part(s): RU7-0350-000CN

LOWER PICK-UP GUIDE ASSY. - RM1-9192-000CN

Pick-up lower guide assemblyThis part replaces the following part(s): RM1-4980-000CN

CLUTCH, ELECTROMAGNETIC - RM1-8946-000CN

Electromagnetic clutch (CL1)
